Controllablereal - Timely Handheld 3D Laser Scanner , Portable 3D Scanner Measure Anywhere

Name: Controllablereal Timely Handheld 3D Laser Scanner Portable 3D Scanner Measure Anywhere
Brand: Sinowon
Price: 1 USD

China Controllablereal - Timely Handheld 3D Laser Scanner , Portable 3D Scanner Measure Anywhere factory

Brand Name : Sinowon

Certification : CE

Place of Origin : China

MOQ : 1 set

Supply Ability : 30 sets per month

Delivery Time : 15 days

Packaging Details : carton

Payment Terms : L/C, T/T, Western Union

Weight : 0.83kg

Measuring rate : 480,000 measure/s

Accuracy : up to 0.02mm

Resolution : up to 0.05mm

Reference distance : 300mm

Depth of focus : 250mm

Contact Now

Controllablereal-timely 3D Handheld Laser Scaning , Measure Anywhere

1.Product Description

Our 3D scanner can be matched up with Sinowon software platform which is a type of powerful processing software. The creative algorithm core helps users quickly acquire the 3D data of object and real-timely preview and edit the scanning data.

The scanning process is visible and controllablereal-timely, to effectively reduce the rework times and improve the working efficiency.

2.Characteristics

Freedom: All-dimensional scanning of object, not restricted by part dimensions materials, color and complexity, etc
Industrial measuring accuracy: up to 0.02 mm
Resolution: up to 0.05 mm Third-party traceability certification
Triangular self-positioning technology part freely movable, fixed installation not required, assured high accuracy
Creating smart grid and seamlessly connecting with the main 3D software to improve the working efficiency

3.Applications

Die & Mould
Furniture
Industrial Design
Automobile

Controllablereal - Timely Handheld 3D Laser Scanner , Portable 3D Scanner Measure Anywhere

4.Specifications

Weight	0.83 kg
Dimensions	310×147×80 mm
Measuring rate	480,000 measure/s
Scanning area	275×250 mm
Light source	14 laser lines(+extra 1 beam)
Laser class	Class Ⅱ(eyes safety)
Resolution	up to 0.05 mm
Accuracy	up to 0.02 mm
Volume accuracy	0.02+0.06 mm/m
Volume accuracy (combined with PhotoShot)	0.02+0.025 mm/m
Reference distance	300 mm
Depth of focus	250 mm
Output format	.asc,.stl,.obj,.ply,.txt,.xyz. etc., customizable
Transmission	USB 3.0
Operating temperature	0-40℃
Operating humidity	10-90%
Compatible software	3DSystem (Geomagic Solutions),InnovMetric Software (PolyWorks),Dassault Systemes (CATIAVS and SolidWorks),PTC (Pro/ENGINEER),Siemens (NX and Solid Edge),Autoesk (Inventor,Alias,3ds Max,Maya,Softimage)
